New Productsmore>>
  • BAC Brand Cooling Tower Parts BAC Brand Cooling Tower Parts Axial Fans 1.Standard fan is high – efficiency and low sound 2.Rugged,aluminum construction for corrosion resistance and extended life 3.Reduced sound levels, Low Sound Fans, Whisper Quiet Fans, and sound attenuation are available. 4.Maintain thermal performance as originally certified by CTI 5.Most fan kits include bushing and special length bolts 6.Available in sizes from 24” to 156” diameter , 4 blades to 12 blades to 12 blades for economical and quiet operation. Centrifugal Fans 1. Low sound 2. Maintain thermal performance as originally certified by CTI 3. Complete installation kit includes hardware , adhesive , and clamps 4. Availability: available in 15” ,18” ,22” ,and 30” diameters for shafts 1-3/16” to 5”in diameter.
  • Marley (SPX) Brand Cooling Tower Parts Marley (SPX) Brand Cooling Tower Parts Kinds of Marley Brand Cooling Tower Prats, cooling tower fans, cooling tower fills, cooling tower drift eliminators, cooling tower belt reducer, vibration switch, motor, water distribution system, make-up float valve, pan strainer, louvers, fan motors, fan shaft and bearings, ect.
  • Evapco Brand Cooling Tower Parts Evapco Brand Cooling Tower Parts Kinds of Evapco Brand Cooling Tower Prats, cooling tower fans, cooling tower fills, cooling tower drift eliminators, vibration switch, motor, water distribution system, make-up float valve, pan strainer, louvers, fan motors, fan shaft and bearings, ect.
  • Evapco cooling tower fills Cooling Tower Infill EVN-300 Replacement of Evapco cooling tower infill is specially designed to induce highly turbulent mixing of the air and water for superior heat transfer. The fill is constructed of PVC, will not rot or decay. Because of the unique way in which the cross-fluted sheets are bonded together, and the bottom support of the fill section, the structural integrity of the fills is greatly enhanced, making the fills usable as a working platform.
  • Counter flow cooling tower fills Cooling Tower Counter Flow Film Fill NSN-30 500x1000mm , cooling tower fills,  Material: Black PVC Dimension:     500x1000mm                        500xany Sheet space: 30 / 33mm Sheet thickness: 0.25-0.35mm Applicable water temperature: 75℃ ~ -35℃ Applicant: counter flow square type cooling tower, Power plant cooling tower fills, NH3 plant cooling tower fills, Industrial cooling tower fills
  • SMC FRP Cooling Tower Fan Stack SMC FRP Cooling Tower Fan Stack NEWIN SMC FRP Cooling Tower Fan Stack Features: ■. Molded SMC Fan Stack, beautiful appearance, smooth surface, low wind resistance  ■. Accurate size and good air tightness, Formed under high temperature and high pressure, accurate size and great air tightness. ■. Molded FRP fan stack has a forming pressure of 1200 tons, molding temperature of 150 ° C to make sure high density, high compactness, high strength and low deformation of the products. ■. High production efficiency --- a set of molded mold could produce 3 sets of products per day (3x2x48 pieces) for 9.754meters diameter fan stack ■. Standardized fan stack, easy to install and greatly reduced installation time ■. Environmental Friendly comparing with traditional hand paste fan stacks, protects workers' health and little scraps Structure of the molded SMC Fan stack FRP molded air cylinder is divided into upper and lower parts, 360° is divided into several equal parts and connected by screws. Parameters of NFS series SMC Fan Stack  2.2 m (meters) height SMC fan stack  For Fan Diameter: 4.7m, 5m, 5.5m, 6m  3.0 m (meters) height SMC fan stack   For Fan Diameter: 4.7m, 5m, 5.5m, 6m, 7m, 7.7m, 8m, 8.53m   3.8 m (meters) height SMC fan stack  For Fan Diameter: 7m, 8m, 8.53m, 9.14m, 9.754m, 10.36m   Model H1 (mm) H2 (mm) H3 (mm) Φ (mm) Φ3 (mm) Φ1 (mm) Φ2 (mm) Nos of pcs  per set NFS-4.7-2.2 2200 1200 300 4760 4890 5664 5844 24 NFS-5.0-2.2 2200 1200 300 5060 5190 5964 6144 28 NFS-5.5-2.2 2200 1200 300 5520 5650 6424 6604 28 NFS-6.0-2.2 2200 1200 300 6060 6190 6964 7144 32 NFS-4.7-3.0 3000 1200 300 4760 4998 5664 5844 24 NFS-5.0-3.0 3000 1200 300 5060 5298 5964 6144 28 NFS-5.5-3.0 3000 1200 300 5520 5758 6424 6604 28 NFS-6.0-3.0 3000 1200 300 6060 6298 6964 7144 32 NFS-7.0-3.0 3000 1200 300 7060 7298 7964 8144 36 NFS-7.7-3.0 3000 1200 300 7760 7998 8664 8844 40 NFS-8.0-3.0 3000 1200 300 8070 8308 8974 9154 40 NFS-8.5-3.0 3000 1200 300 8610 8848 9514 9694 44 NFS-7.0-3.8 3800 1650 400 7060 7404 8472 8652 36 NFS-7.7-3.8 3800 1650 400 7760 8104 9172 9352 40 NFS-8.0-3.8 3800 1650 400 8070 8414 9482 9662 40 NFS-8.5-3.8 3800 1650 400 8610 8954 10022 10202 44 NFS-9.14-3.8 3800 1650 400 9220 9564 10632 10812 48 NFS-9.75-3.8 3800 1650 400 9834 10178 11246 11426 48 NFS-10.36-3.8 3800 1650 400 10460 10804 11872 12052 52 Remark: Thickness for upper parts: middle area: 3mm, edge area: 8-12mm                Thickness for lower parts: midd area: 4mm, edge area: 8-12mm Projects of SMC FRP Cooling Tower Fan Stack Manufacturing of SMC FRP Cooling Tower Fan Stack
Hot Productsmore>>
  • cooling tower reducer Cooling Tower Belt Reducer At present, the main transmission methods for mechanical draft cooling tower are multi-polar direct drive motor, belt type reduction drive, gear reducer drive, hydraulic turbine drive etc. Belt type reduction drive is widely application, through the tension in the pulley of the driving wheel and driven wheel belt for the power transfer to a mechanical transmission, it has a simple structure, stable transmission, can buffer vibration absorption, can be in large axial spacing between shaft and transmission power, low cost, without lubrication, easy maintenance and other characteristics, widely used in the cooling tower and a number of mechanical equipment.  Below is the Marley cooling tower belt reducer specification.
  • Evapco Cooling Tower Drift Eliminator Newin Cooling Tower Drift Eliminator NEWIN EVD eliminators Drift eliminators remove small droplets of water that are entrained in the exhaust air to minimize the nuisance and health issues that they create if allowed to escape through the top of the tower along with the heated air. Drift eliminators are designed to create a tortuous path for the air stream. When the water droplets move through them, they are forced to change direction and impact the drift eliminator side walls, coalescing and draining back into the wet section of the cooling tower. The drift eliminators are constructed of an inert polyvinyl chloride (PVC) plastic material which effectively eliminates corrosion of these vital components. They are assembled in sections to facilitate easy removal for inspection of the water distribution system. Feaures ■ Anti-aging, high water absorption ■ low airflow resistance, high strength ■ easy installation and long service life ■ can be the replacement of air inlet louver Specification Model--EVD PVC Max.length depend on customer demand Width depend on customer demand Height 145 mm Continuous operation tempperature 50℃ Max.applicationtemp. (short term) 60℃ Color  Black Application                    Counter flow cooling tower Packing and Loading:  LCL shipment: by plywood pallet/case/carton, FCL shipment: by container Trade Terms: EXW, FOB, CFR,CIF, DDU. Payment term: T/T, L/C, West Union Minimum Order Quantity: 1000pcs Structure Drawing NVD drift eliminator Pictures --- cooling tower drift eliminator  PVC Plastic sheet(after molding) Physical and mechanical property No. Item symbol unit index test method 1 density ρ g/cm3 ≤1.55 GB/T 1033 1-2008 2 tensile strength lengthways σt MPa ≥42.0 GB/T 13022-91 crosswise ≥38.0 3 tear strength lengthways σtr kN/m ≥150 GB/T 1130-91 crosswise ≥160 4 Folded in half Coldness Resistance Temperature ordinary type tb ℃ ≤-8 DL/T 742-2001 Frigostabile type ≤-18 5 oxygen index OI -- ≥30 GB/T 2406 1-2008 Replacement for other brand cooling towers: Our drift eliminators are modular PVC drift eliminators that most of modern cooling towers  which are easily re-fitted with our new PVC drift eliminators.They are perfect for older cooling towers as replacement.
  • BAC cross flow cooling tower replacement fills BAH Series 1330 x any length BAC Cooling TowerPVC Fills BAC cooling tower high quality replacement film fills, 3-years quality guarantee. Dimension: 1330 x 2450 mm                        1330 x 2560 mm                          1330 x 2880 mm or any Sheet space: 19 mm Sheet thickness: 0.35-0.4 mm (customized available)     Application: BAC cooling tower 3000 series, 1500 series, closed cooling tower FXV series.
  • Marley fills MAH Series 1220 x 1854mm Marley Cooling Tower PVC Fills Dimension: 1220x1854mm; PVC sheet thickness: 0.3-0.5 mm Sheet spacing: 18mm Marley(SPX cooling tower) replacement fills, 3 years quality guarantee. Specification:  Dimension:    1220*1854mm                     1220*2260mm                     1220*2472mm                      1220*any Sheet space: 19mm Sheet thickness: 0.33-0.35mm Applicant: Marley(SPX)cross flow square type(box type) cooling tower
  • Direct-connected Planetary Gear Reducer -- NDQ Series Direct-connected Planetary Gear Reducer -- NDQ Series Direct-connected Planetary Gear Reducer -- NDQ Series The speed reducer is a direct-connected planetary gear reducer, adopts a hard tooth surface technology.  Structure is compact, light weight and high torque.           Features - Compact structure, strong overload capacity.   - Light weight and small size.   - Easy installation and maintenance.   Model Description Model Motor Specification Noise Value (JM Distance ) Motor Weight  (KG ) Gear Box  Weight   ( KG ) Reducer  Weight  ( KG ) NDQ 132-4-165 V1  4kw-6(132M1) 67 64 55 119 NDQ 132-4-210 V1  4kw-4(112M)(+) 68 46 55 101 NDQ 132-4-250 V1  4kw-4(112M)(+) 68 46 55 101 NDQ 132-4-320 V1  4kw-4(112M)(+) 68 46 55 101 NDQ 132-5.5-165 V1  5.5kw-6(132M2) 67 75 55 130 NDQ 132-5.5-210 V1  5.5kw-4(132S1) 68 59 55 114 NDQ 132-5.5-250 V1  5.5kw-4(132S1) 68 59 55 114 NDQ 132-5.5-320 V1  5.5kw-4(132S1) 68 59 55 114 NDQ 132-7.5-210 V1  7.5kw-4(132M) 68 72.5 55 127.5 NDQ 132-7.5-250 V1  7.5kw-4(132M) 68 72.5 55 127.5 NDQ 132-7.5-320 V1  7.5kw-4(132M) 68 81 55 136 NDQ 160-11-165 V1  11kw-6(160L) 68 147 83 230 NDQ 160-11-210 V1  11kw-4(160M) 70 107 83 190 NDQ 160-11-250 V1  11kw-4(160M) 70 107 83 190 NDQ 160-11-320 V1  11kw-4(160M) 70 107 83 190 NDQ 160-15-165 V1  15kw-6(180L) 70 190 83 273 NDQ 160-15-210 V1  15kw-4(160L) 70 144 83 227 NDQ 160-15-250 V1  15kw-4(160L) 70 144 83 227 NDQ 160-18.5-210 V1  18.5kw-4(180M) 70 153 83 236 NDQ 160-18.5-250 V1  18.5kw-4(180M) 70 153 83 236 NDQ 160-22-210 V1  22kw-4(180L) 70 170 83 253 NDQ 160-22-250 V1  22kw-4(180L) 68 170 83 253 NDQ 200-15-125 V1  15kw-6(180L) 73 144 148 292 NDQ 200-18.5-165 V1  18.5kw-4(180M) 73 153 148 301 NDQ 200-18.5-210 V1  18.5kw-4(180M) 73 153 148 301 NDQ 200-22-165 V1  22kw-4(180L) 73 170 148 318 NDQ 200-22-210 V1  22kw-4(180L) 73 170 148 318 NDQ 200-22-250 V1  22kw-4(180L) 73 170 148 318 NDQ 200-30-165 V1  30kw-4(200L) 73 228 148 376 NDQ 200-30-210 V1  30kw-4(200L) 73 228 148 376 NDQ 225-37-165 V1  37kw-4(225S) 73 270 148 418 NDQ 225-37-210 V1  37kw-4(225S) 73 270 148 418 NDQ 225-45-165 V1  45kw-4(225M) 73 280 215 495 NDQ 225-45-210 V1  45kw-4(225M) 73 280 215 495   Installation   Model NDQ132 NDQ160 NDQ200 NDQ225 Size A 380 430 490 540 B 340 390 450 500 C 100 100 130 130 D 60 60 80 80 E 14 16 16 16 F 8/10 12/14 14/16 18 G 230 250 340 350 H 17.3/22.3 24.3/27.8 27.8/31.8 34.4 I 28/38 42/48 48/55 60 J 19 19 19 19 K 300 350 400 450 L 265 300 365 400 M 235 272 365 371 N 300 358 405 460 O 209 211 229 249 P 115(1:10) 115(1:10) 115(1:10) 135(1:10) Q 55 60 70 80 R 31.8 34.4 39.9 45.4 S 16 18 20 22 Other types of Gearbox  Click below picture for knowing more details about other seires
  • NS-01 ZM Cooling Tower Spray Nozzles ZM Cooling Tower plastic spray nozzles  ZM nozzles are gravity flow and could easily be inspected and replaced while the equipment is in operation. Large orifice make sure non-clogging performance for effective wetting of the heat-transfer surface.
